Linear wrap-around labeler for pails

Link Pack

The Link-Pack linear labeler offers the opportunity to process several sizes of pails with handles. The system is user-friendly and only requires placing a pail or container with its handle against the guide to allow an unobstructed rotation during label application. The guide stabilizes conical containers, preventing misalignment during label application. The containers are seized by a motorized 3-point aligner that rotates the containers. During this phase, your choice of one or two labels can be applied to the container from the same *label roll.



A guide maintains the handle horizontally while the labels are being applied.  A second guide located on top of the pails will keep the container from lifting during the rotation, due to the conical design.  Such a movement would result in inaccuracies in label placement in addition to wrinkles.



The labeled containers can be removed by hand or automatically transferred to another conveyor for the next step in your process. Electronic settings for each format can be stored for quick and easy adjustments. All our labelers are inspected and approved by CSA to ensure electrical compliance.



This labeler is suitable for companies that want to increase the accuracy and efficiency of their labeling operations. Its rugged open frame is built with a stainless steel frame. It is constructed with high-quality components such as a motorized 3-point aligner, Allen Bradley touch screen and PLC, Herma 500 label applicator, and a 6″ wide x 8′ long motorized conveyor.



The Link-Pack wrap-around labeler can reach speeds of 25 containers/minute. It is designed and assembled in Quebec by our team, which also provides fast and reliable technical support.



If you are looking for full Wrap Labeling of Paint cans with ears please see our Wrap Around Labeler with Container Orientation



Category:

Labelers / Pressure-Sensitive / Container Orientation




    Étiqueteuse pour chaudières rondes

    Features

    High quality construction and 304 stainless steel frame mounted on adjustable legs

    Optical sensor for positioning

    Handle Guide

    Allen Bradley PLC & HMI

    Herma 500 servo label head

    Controled by Allen Bradley PLC and HMI

    Herma servo label head

    Compliant to safety CSA regulations

    FDA-approved seamless belt conveyor

    Options

    Container Handling System

    Single Lane Discharge Conveyor

    Complete Protective Guarding

    Additional Label Applicator Head

    Specifications

    For any round containers

    Speed up to 25 per minute

    208V, 1ph, 60Hz

    300mm (11.5'') diameter label rolls

    160mm (6'') label height (standard)

    Compact footprint: 90`` L x 30`` W
