Linear Scale / Weigh Filler

Actionpac MINI109

The MINI109 is a complete and straightforward net weigh filler specifically designed to distribute and bag small quantities of fresh produce or cheeses as well as dry powdered or granular, free-flowing products like spices, grains, and seeds. Product distribution ranges from 10g – 250g weights at a rate of 8-12 bags/minute


Similarly to the Me109 and ME1095, this linear scale is offered as a semi-automated system for operator-assisted filling or as a fully automated system. The automation of the scale usually requires a conveyor and container indexing system which are both available and integrated by Link Pack.


Full wash-down and integrations are available. Other options include electropolishing, multiple ingredient blending, product elevators and floor hoppers.


Accessories / Net Weigh Fillers / Scales

    Net Weigh Filler / Linear Scale


    High speed and high weight accuracy of 1/100oz (1/10 grams) 0.1 g

    Easy maintenance: easily accessible mechanical parts, simple open design. Free lifetime support.

    Long lasting equipment: all metal parts in stainless steel, except the vibrator unit


    Hopper capacity: up to 40lbs

    Electricity: 115 VAC, 3 amp, 60 Hz

    Footprint approx. W 32`` x D 33``
